The VODO-AFQ cabinet series parallel multifunction active filter is the most complete solution for solving Quality problems related to industrial, commercial or services installations with presence of harmonics, consumption of reactive power (usually capacitive) and also phase unbalance. This VODO-AFQ is meant rack mounting into market standard cabinets, designed to facilitate its installation. If higher capacities are required, the system can be expanded with VODO-AFQ racks in parallel.
| Technical parameter性能参数 | |
| Rated voltage额定电压 | AC380V~AC750V±10% |
| Rated frequency额定频率 | 50Hz/60Hz±2% |
| Connection mode电网类型 | 三相三线/三相四线 |
| Capacity有效容量 | 25~150A/kvar |
| Harmonic补偿谐波阶次 | 2~50次 |
| Power factor correction功率因数校正 | -1~+1 |
| Parallel expansion最大功率扩展 | 8台（并联） |
| Power waste额定功耗 | ＜2kw |
| Efficiency设备效率 | ≥98% |
| Signal communication通信接口 | RS485 |
| Altitude海拔高度 | ＜1000m，降容运行1.7%每100m可达2000m |
| Ambient temperature运行环境温度 | -10℃~+55℃ |
| Ambient humidity环境湿度 | ＜95%RH，无凝结 |
| Vibration振动 | ＜5.9米/秒2（0.6g） |
| Protection level防护等级 | IP4X |
| Cooling mode冷却方式 | Intelligent air cooling智能风冷 |
| Installation mode安装方式 | Rack/ Wall mounted机架式/壁挂式 |
| Interference level无线电干扰水平 | EN55011，Group 1，Ciass A |
| Immune interference level无线电干扰免疫水平 | EN61000-4-2 and EN61000-4-5 |
