Equipment description
VODO-TSC thyristor switch is an electronic power device that can switching capacitors quickly. It is also called thyristor switch. It mainly consists of high-power thyristor, isolation circuit, trigger circuit, synchronous circuit and protection circuit. The utility model has the advantages of zero-crossing voltage input, no inrush current, zero-crossing voltage cut-off, no high voltage, no additional harmonics and no noise in all waveguides.
| Technical parameter性能参数 | |
| Working voltage工作电压 | AC220V±15% |
| Rated current额定电流 | ≤150A |
| Control voltage控制电压 | DC12V/10mA |
| Rated Frequency额定频率 | 50Hz |
| Reverse Voltage反向耐压 | ≥2200V |
| Current inrush投入涌流 | ＜1.8In |
| Switching time投切时间 | ≤10ms |
| Ambient temperature环境温度 | -25℃~+90℃ |
| Service life使用寿命 | 100万次 |
| Altitude海拔高度 | ≤4000m |
| Aelative humidity相对湿度 | ≤90% |
| Power network harmonic电网谐波 | Voltage harmonic distortion rate电压谐波畸变率≤5% |
